A look at the internals of the Rotary Phone. Way more messy than when I first got it.

Changed my mind on a design choice for the phone circuit. I'm going to hook up GPIO9 (command mode toggle) to the Arduino so that I can easily go in and out of command mode in firmware.

I'm going to need this for another firmware I'm going to write to make this phone into a Jukebox. Have my comput...

Complete

Final Schematic is done! Now I just got to build a github page.

Note: Everything I'm doing here is going to be Public Domain.

Edit: Found a mistake in this schematic. GPIO7 is what is suppose to go to ground, not GPIO6. I will correct this in schematic before I post on github.

I've been told by the organizer of http://bsideshuntsville.org/ to present my rotary phone at this coming bsides. My idea for displaying the phone will be writing jukebox software on my Mac which listens for the number being dialed on the rotary phone. Depending on the number dialed, the computer...

Here I'm playing with the Music Player part of the Rotary Phone project. Works Well.
